Multifunctional Adjustable Glass Lifter for Curved Glass
This multifunctional adjustable glass lifter has a capacity of 600 kg. The suction pads can be adjusted in depth up to 250 mm, making it ideal for uneven glass sections. There is also a choice between a short or long lifting arm, allowing the lifting point to be positioned closer to or further from the lifter.
For perfect vertical alignment of glass panels or façades, the lifter can be equipped with a spreader beam with electrically adjustable counterweight.
Specifically Developed for Curved Glass
The lifter was specially designed for handling both concave and convex glass panels, based on a reference radius of 1850 mm.
Suitable for:
-
cylindrical glass
-
molded and double-curved glass
The design accounts for the varying distance between the lifter frame and the glass, essential when dealing with complex shapes.
Key Features
-
Depth-adjustable suction pads up to 250 mm
-
Optional electrically adjustable counterweight
-
Compensation for natural rotation tendencies of curved elements
-
Maximum control and stability when lifting curved glass
Wirth GL-M1200-SPECIAL
Technical specifications
Downloads
C-hook 750
What is a C-hook?
A C-hook is a lifting device in the shape of the letter “C,” designed for safely and efficiently lifting loads such as glass plates, metal coils or other heavy objects. The design allows for lifting loads in situations with limited space or obstacles, such as roof overhangs or facades.
Applications of C-hooks
Glass installation:
C-hooks are often used in combination with vacuum lifters to hoist glass panes over obstacles and precisely position them during façade installation.Coil handling:
In industrial environments, C-hooks are used to transport metal coils.Limited space:
Due to their shape, C-hooks are ideal for use in restricted areas where traditional lifting gear cannot fit.
Features
Shape:
The C-shape allows for lifting without the hook obstructing the load.Capacity:
C-hooks are available in various capacities, ranging from a few hundred kilograms to several tons, depending on the model and manufacturer.Material:
Typically made from high-grade steel for strength and durability.
Technical properties
Capacity
750 Kg
Own weight
85 kg
